E15WLI-5 - Schedule 5 Female E-Line Long Ferrule

View Dimensions

Dimensions

OD Tube Size	A, in.	A, mm.	B, in.	C, in.	C, mm.	D, in.	D, mm.
1	1.315	33.4	1.185	2	50.8	1.75	44.45
1.5	1.9	48.26	1.77	2.648	67.26	2.031	51.59
2	2.375	60.33	2.245	3.317	84.25	2.312	58.72
2.5	2.875	73.03	2.37	3.868	98.25	2.5	63.5
3	3.5	88.9	2.87	4.882	124	2.687	68.25
4	4.5	114.3	3.834	5.882	149.4	3	76.2

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	1
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	1
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	1.315
A, mm.	33.4
B, in.	1.185
C, in.	2
C, mm.	50.8
D, in.	1.75
D, mm.	44.45

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	1.5
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	1.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	1.9
A, mm.	48.26
B, in.	1.77
C, in.	2.648
C, mm.	67.26
D, in.	2.031
D, mm.	51.59

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	2
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.375
A, mm.	60.33
B, in.	2.245
C, in.	3.317
C, mm.	84.25
D, in.	2.312
D, mm.	58.72

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2.5
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	2.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.875
A, mm.	73.03
B, in.	2.37
C, in.	3.868
C, mm.	98.25
D, in.	2.5
D, mm.	63.5

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	3
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	3
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	3.5
A, mm.	88.9
B, in.	2.87
C, in.	4.882
C, mm.	124
D, in.	2.687
D, mm.	68.25

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	4
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Male E-Line X Schedule 5 Pipe
OD Tube Size	4
Wall Thickness	0.083
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	4.5
A, mm.	114.3
B, in.	3.834
C, in.	5.882
C, mm.	149.4
D, in.	3
D, mm.	76.2
