E31I-14I-15I - Male E-Line X Female E-Line Concentric Reducer

E31I-14I-15I - Male E-Line X Female E-Line Concentric Reducer

Material Type
Size

View Dimensions

Dimensions

E31I-14I-15I - Male E-Line X Female E-Line Concentric Reducer

OD Tube Size	A, in.	A, mm.
1.5X1.0	3.531	89.69
2.0X1.0	5.562	141.27
2.0X1.5	3.718	94.44
2.5X1.5	5.781	146.84
2.5X2.0	4.875	123.83
3.0X1.5	7.843	199.21
3.0X2.0	5.937	150.8
3.0X2.5	4.062	103.17
4.0X2.0	10.062	255.57
4.0X2.5	8.187	207.95
4.0X3.0	6.25	158.75
6.0X3.0	7.406	188.11
6.0X4.0	7.875	200.03
